Flame Retardant Low Smoke Low Halogen Up to 1100 V

Applications : Suitable for use in conduit and for fixed protected installation particularly suitable for wiring in fire and explosion prone areas, chemical factories, densely wired areas, public buildings, schools, hospitals, commercial complexes, theatres, etc

Conductor : Many thin strands of Electrolytic Copper are fine-drawn simultaneously for uniformity of Resistance, Dimension, and Flexibility. The drawn strands are twisted in high precision machines which imparts circularity to the conductor.

Insulation : Specially formulated grade of Flame Retardant Low Smoke Low Halogen compound to restrict the spread of flames in fire situation. The smoke emitted by the burning cable is considerably low compared to traditional cables. This ensures improved visibility for evacuation of trapped victims and facilitates fire fighting operation.

Insulation Conformity : IS 5831 Type A FR-LSH

Approvals : IS 694 marked, FIA/TAC approved – CM/L 7205255

Colours : Entire cable has White base and a double strip of Red, Yellow, Blue, Black, Green running along the length of the cable

Packing : 90 mtrs. coils packed in protective cartons. Project coils of 180 mtrs also available.
